Jewers Doors - Sliding Hangar Doors

Entering its 28th year, Jewers Doors remains at the forefront of hangar door technology. The UK-based company now has unrivalled expertise in designing and manufacturing its class-leading Esavian doors for installation in the very largest hangars around the world. The most recent of a number of door installations for A380 aircraft hangars is the massive maintenance hangar at New Doha International Airport, Qatar.

Developed continuously over many years, Esavian doors have sophisticated control systems to reduce temperature changes when doors are opened and a multitude of safety features. A wide choice of cladding materials is available and Esavian doors are suitable for the harshest environments. In addition to doors for very large hangars, Jewers Doors designs and manufactures doors for hangars of all sizes including those for light aircraft and helicopters.

While Esavian doors are often specified for new-build projects, they are equally suitable for refurbished hangars and will give long, low maintenance service.

Jewers Doors has clients on every continent which include commercial airlines, MRO companies, the military, businesses and private individuals.

Straight sliding doors for aircraft hangars

The flagship of the Esavian range, the TYPE 126 straight sliding door has been installed on the largest hangars in the world. With an unlimited span, it is also the most popular and cost-effective form of hangar door available.

The steel-framed construction of these bottom-rolling, sliding doors accepts any cladding or glazing system (or cladding/glazing combination) and can incorporate in-built truck doors and personnel doors.

Key features include:

• Robust steel construction bottom rolling, sliding door
• State-of-the-art drive systems with user-friendly controls
• Multiple safety devices available
• Heights ranging from 6m to 40m and unlimited width
• Unlimited choice of cladding, glazing, colours and configurations
• Full weather-sealing

Mid-range sliding hangar doors

The TYPE 127 in Esavian's mid-range sliding door, which utilises our robust Phoenix range composite panels to provide modular, visually appealing leaves.

With a maximum height of 12m and unlimited width, the 127 is ideally suited for smaller aircraft hangars or larger vehicle openings.

Key features include:

• Unique rigid flat composite panel cladding system used on Phoenix doors
• Framed using hot rolled steel box section
• To suit opening heights from 6m up to 12m, and of unlimited width
• Single or multi-track format, bottom rolling
• High insulation values with full weather-sealing
• Electrically operated or manual operation available
• Unlimited choice of control or drive systems
• Factory finished to any RAL colour
• Choice of glazing available
• Wicket doors provide personnel access

Aluminium folding hangar door

With its all-aluminium construction, the Esavian TYPE 1200 bottom rolling, folding door has an unbeaten track record of durability and longevity on aircraft hangars the world over. The earliest examples of this door are still in operation at Airbus in Bristol and at Liverpool Airport - each dating back more than 50 years. Other examples have served over 30 years in the Middle and Far East, where extremely dusty and windy conditions are experienced regularly.

The 1200 is designed for particularly tall openings (between 8m and 18m high) and unlimited width, making it a perfect door for apertures when stacking space is at a premium.

Key features include:

• Extremely robust, durable marine grade aluminium construction
• Power operated for ease of use
• No load bearing portal frame required - weight of door taken on floor
• Bottom rolling on a single flush floor track
• Leaves can be stacked in any position within or clear of the opening
• Large number of safety features and control methods available
• Fully factory finished to any colour
• Optional glazing and personnel doors
• High standard of weather seals to all joints
• Heights from 8m up to 18m plus unlimited width

Insulated steel hangar door

The Flatfold door is a mid-range folding door from the Esavian line up. This bottom-rolling, insulated, steel door is suitable for openings up to 30m wide by 8m high. It is ideal for large helicopter, or medium-sized aircraft hangars. When open, the door leaves fold clear of the opening into small bunching areas, thus providing full opening width and height without compromising hangar space.

Key features include:

• For openings up to 8m high by 30m wide
• No load-bearing portal frame required - door weight taken on floor
• Power operated as standard
• Minimal bunching space. A 30m wide bi-parting door will bunch into under 2m beyond each jamb
• Hand wind versions available
• Control system postioned on front edge of door to allow operative to 'walk' the door open and closed
• Inverter control provides smooth acceleration and deceleration during start-up and stopping
• Full factory finish available in any colour
• Door frames, mullions and sliding posts are galvanised prior to final finish
• Single bottom track set flush into floor
